Gantry Milling Machine LMD4000

The size of LMD4000 series is usually customized according to the machining requirements of the field conditions. Standard configurations include a 4000mm long X axis and an optional Y axis ranging in length 1000-3000mm.

LMD4000 Gantry Milling Machine

It’s common applications include on-site milling flat steel frame structures, large scale motor bases, engine blocks, ship propellers, impellers, contoured machine parts, as well as critical mounting surfaces of various machinery in the oil and gas industry.

Products Detail

  • Standard with 4000mm main bed.
  • The standard cantilever length is 1000mm, 2000mm, 3000mm optional.
  • Spindle speed (R.P.M): 0-740 r/min stepless speed regulation.
  • Two types of spindle taper NT40 & NT50 are optional.
  • Standard equipped with 26KW 3 outputs hydraulic station power system.
  • Optional pneumatic power system with 3KW, 2.69 m3/min pneumatic motor.
  • The leveling of the main bed depends on tuning jacking screws and fixing bolts in each leveling foot.
  • The X axis feed system uses trapezoidal screw and a dual rack synchronous module.
  • The Y axis feed system uses a ball screw to achieve higher finishing accuracy.
  • The main bed can be fixed to the workpiece by welding or using a magnetic base.
  • Universal milling heads and carbide inserts, allowing you to purchase replacements locally.
  • A wide range of different parts and materials can be used thanks to the powerful hydraulic system.

PORTABLE DESIGN

The modular design allows it to switch between gantry milling mode and linear milling mode functions, the orbital, canteliver, spindle unit, and power system can be individually assembled to achieve optimal portability.

Gantry Milling Mode

Max Range: 4000*3000mm

Line Milling Mode

Range:

MAIN BED

X axis(Main bed) consist with:

  • 2 * 4000mm forged steel high-precision heavy-duty linear guide rail.
  • 2 * adjustable length guide rail connecting rod.
  • Dual gear box synchronous output system with adjustable length drive rod.
  • Standard equipped with trapezoid double rack for sychronous feed, ball screw feed optional.
  • There are two kinds of mounting bases available: standard base and magnetic base. 1. Standard base allows the machine to be welded or bolted to the workpiece. 2. Magnetic base allows the machine quick attached to the workpiece by magnetic force.
  • Quick installation kit.

CANTELIVER

Y axis(Cantilever) outfitted with:

  • Aluminum arm with optional standard length 1000mm, 1500mm, 2000mm, 3000mm to reduce the weight.
  • Double guide rails inserted into the aluminum arm.
  • Ball screw feed system, ensure Y-axis feed is more accurate, the end has manual, pneumatic and hydraulic interfaces.
  • Spindle head installation plate fixed in the guide rails.

MILLING SPINDLE HEAD

Z axis(Milling spindle head):

  • Allows 90° and 180° degree installation.
  • Equiped with digital scale.
  • Optional milling spindle head NT40 or NT50.
  • NT40: Face Mill diameter 160mm.
  • NT50: Face Mill diameter 200mm.

NT40

cutter diameter: 160mm

NT50

cutter diameter: 200mm

POWER SYSTEM

Hydraulic Power Unit (standard)

  • Three outputs for spindle rotation, X axis and Y axis feed.
  • Output power 26KW.
  • Hydraulic flow: spindle head 60L/min, X and Y axis feeding 20L/min.
  • Pressure (MPa): ajustable 0-15 MPa.
  • Power: Three-phase electric power, 220V380V480V575V optional.
  • Three hydraulic motor models are available:
Hydraulic Motor Model Milling RPM
160# 0-355 rpm
200# 0-305 rpm
250# 0-245 rpm

Hydraulic Station

Hydraulic Station Accessories

Pneumatic Power Unit(optional)

  • Three pneumatic motor for spindle rotation, X axis and Y axis feed.
  • One motor to drive the spindle rotation with a power of 3.7KW. Two motors to drive the X-axis and Y-axis feeds with a power of 0.89KW.
Pneumatic Motor (spindle rotation) Pneumatic Motor (feeding)
3.7KW 0.89KW
6-8 bar 6-8 bar
3.56m³/min 1.3m³/min

Pneumatic Motor(spindle rotation)

3.7KW, 6-8 bar, 3.56m³/min

Pneumatic Motor for Feeding

0.89KW, 6-8 bar, 1.3m³/min

TOOL PACK

  • Oiler, used to add lubricating grease to machine tools.
  • Hex Keys Set 1, apply to installation, disassembly and adjustment.
  • Hex Keys Set 2, apply to installation, disassembly and fine tuning.

Oiler

Hex Keys Set 1

Hex Keys Set 2

Code Name Unit Image
104511 Carbide Tip Box(10pcs)
00000 Hydraulic Motor pcs
00000 Quick Connector pcs

Portable Machine Tool Warranties

All new portable machine tools come with a 12 month warranty as standard. Of course, warranty cover does not mean that a machine tool does not need to be serviced, or that parts will not experience wear and tear and, as a consequence, may need to be replaced.

Extended 2 Year Machine Tool Warranties

Depending on a machine tool’s use and application, customers can also opt for an extended warranty to 2 years to provide extra peace of mind and which can help keep machine downtime and repair costs predictable, and to a minimum.

SHIPPING DATA

MODEL DIMENTION(MM) VOLUME(CBM) WEIGHT(KG)
LMD1010 Box1:1520*860*460 0.60 570
Box2:1710*490*560 0.47 150
Box3:1080*940*1460 1.48 680
TOTAL 2.55 1308
LMD1015 Box1:1520*860*460 0.60 570
Box2:2200*490*560 0.60 358
Box3:1080*940*1460 1.48 680
TOTAL 2.68 1508
LMD1020 Box1:1520*860*460 0.60 570
Box2:2500*490*560 0.69 270
Box3:1080*940*1460 1.48 660
TOTAL 2.77 1500
LMD1030 Box1:1520*860*460 0.60 1500
Box2:3500*490*560 0.96 1500
Box3:1080*940*1460 1.48 1500
TOTAL 2.04 1500

Box1

Machine Main Bed

Box2

Canteliver

Box2

Hydraulic Station

Provides superior performing machining activities

Equipped with a 18.5KW hydraulic pump station as standard, it provides strong power for machining. The spindle can adjust the angle within the range of 90°-180°, and the workpiece can be machined at any angle such as horizontal, vertical, inverted, etc.

Offers a mobile and flexible solution

Whether it is a metropolis with well-developed transportation or a remote suburb, only one truck is required for machine delivery, and the modular design offers optimal convenience for transportation and installation.

Cost-effective and versatile

Compared with traditional heavy-duty machine tools, the cost of LMD series on-site machine tools is undoubtedly much lower. This machine tool designed for on-site machining is considered to meet the needs of on-site machining in all aspects, and it is flexible, multi-purpose, and efficient. It is indispensable tool for on-site processing.

Enhances accuracy

The cantilever adopt ball lead screw, heavy-duty linear guides, reduced friction, ensure rigidity, guaranteed for ultimate accuracy.

Technical Data

CATEGORY ITEM LMD4010
STROKE X Axis(auto) 4000mm
Y Axis(auto) 1000mm
Z Axis(manual) 250mm
AUTO FEED Hydraulic 20L/min
Pneumatic 0.89KW, 1.10 m³/min
Feed Rate 35-1000mm/min
MILLING SPINDLE Hydraulic 60L/min
Pneumatic 3KW 2.69 m³/min
Spindle Taper NT40 or NT50
Max Cutter Dia. 160mm(NT40) or 250mm(NT50)
Spindle R.P.M 0-740
POWER SYSTEM Hydraulic Station 26KW
CATEGORY ITEM LMD4020
STROKE X Axis(auto) 4000mm
Y Axis(auto) 2000mm
Z Axis(manual) 250mm
AUTO FEED Hydraulic 20L/min
Pneumatic 0.89KW, 1.10 m³/min
Feed Rate 35-1000mm/min
MILLING SPINDLE Hydraulic 60L/min
Pneumatic 3KW 2.69 m³/min
Spindle Taper NT40 or NT50
Max Cutter Dia. 160mm(NT40) or 250mm(NT50)
Spindle R.P.M 0-740
POWER SYSTEM Hydraulic Station 26KW
CATEGORY ITEM LMD4030
STROKE X Axis(auto) 4000mm
Y Axis(auto) 3000mm
Z Axis(manual) 250mm
AUTO FEED Hydraulic 20L/min
Pneumatic 0.89KW, 1.10 m³/min
Feed Rate 35-1000mm/min
MILLING SPINDLE Hydraulic 60L/min
Pneumatic 3KW 2.69 m³/min
Spindle Taper NT40 or NT50
Max Cutter Dia. 160mm(NT40) or 250mm(NT50)
Spindle R.P.M 0-740
POWER SYSTEM Hydraulic Station 26KW

PRODUCT BROCHURE

LMD SERIES GANTRY MILLING MACHINE

Download
